D3 Tool Steel

Features of D3 Tool Steel

• 1

  D3 Tool Steel is an air hardening, high-carbon, high-chromium tool steel that displays excellent abrasion and wear resistance and has good dimensional stability and high compression strength. D3 Tool Steel is heat treatable and offers hardness in the range of 58-64 HRC. Due to its abrasion resistance in the hardened condition, D3 tool steel machining should be limited to finished grinding.

  D3 tool steel Related Specifications A681-1999

  D3 Tool steel Chemical composition
  C(％) 2.00～2.35  Si(％)  0.10～0.60 Mn(％) 0.20～0.60
  P(％) ≤0.030    S(％)  ≤0.030 Cr(％) 11.0～13.5
  W(％) ≤1.00    V(％)  ≤1.00

  D3 tool steel Form of Supply
  D3 tool steel, we can supply the round bar, flat bar, plate and square block. Diameters can be sawn to your required lengths as one offs or multiple cut pieces. Rectangular pieces can be sawn from flat bar or plate to your specific sizes. Ground tool steel bar can be supplied, providing a quality precision finished bar to tight tolerances.

  D3 tool steel Applications
  D3 Tool Steel is used for Blanking and forming dies, forming rolls, Press tools, Punches, bits and Bushes.

  Physical properties of D3 alloy tool steel
  Density:  7.85kg/cm3
  Hardness at annealing: 255HB Max
  Hardness at quenching and tempering(Q+T):  54-62HRc
  Mechanical properties of D3 tool steel alloy material
  Izod impact unnotched: 28.0 J
  Poisson’s ratio: 0.27-0.30
  Elastic modulus: 190-210 Gpa

  Equivalent metals material l of D3 Tool steel
  AFNOR Z 200 C 12
  DIN WN-r 1.2080
  UNI X 21O Cr 13 KU
  JIS SKD1
  B.S. BD 3
  ASTM A681
  FED QQ-T-570
  SAE J437
  GB Cr12
  UNS T30403


  COLD WORK STEEL冷作模具钢

  编号 NO:	近似钢号					用途	Application
  	中国GB	美国AISI	德国DIN	日本JIS	外企 Foreign Enterprise
  1	Cr12Mo1V1	D2	1.2379	SKD11		量产冲压模，剪切刀模，搓丝模、瓷制品模等	For pounch mold,knife mold,screw mold,chinawae mold
  2	*Cr12Mo1V			SKD10		量产冲压模，剪切刀模，搓丝模、瓷制品模等	For pounch mold,knife mold,screw mold,chinawae mold
  3	Cr12MoV	D5	1.2601			量产冲压模，剪切刀模，搓丝模、瓷制品模等	For pounch mold,knife mold,screw mold,chinawae mold
  4	Cr12	D3	1.2080	SKD1		耐磨挤压工具与导向板等	For wear-resisting press tool and guide palte etc
  5	*Cr8Mo2WVSi				ASSABBB	类于D2,但韧性好，更适宜线切加工	Similer D2,better toughness.
  6	Cr12W	D6	1.2436			冲压模、挤压模、拉伸模	For pounch mold,press mold,mech mold
  7	*5Cr8Mo2VSi	A8	1.2631			耐磨薄刃剪切刀具、压铸配件等	For weat-resisting cutter with thin knife edge
  8	Cr5Mo1V	A2	1.2363			重载及形状复杂冲压模，剪切刀具	For pweat-resisting cutter with thin knife edge
  9	9CrWMn	O1	1.2510	SKS3	BOHLERK460	薄冲压模，手饰压模	For thin pounch mold,headgear mold
  10	*9Cr2MoV		1.2327		BOHLERK310	量刃具、冷轧辊、滚丝轮等	For cold rolling roller,thread wheel
  11

  编号 NO:	冷作模具钢化学成份(% ) Chemical composition										退火状态 硬度≤ Annealed Hardness	热处理温度(℃) Heal treatment temp		回火硬度 HRC Secondary hardness
  	C	Si	Mn	P≤	S≤	Cr	W	Mo	V			淬火  Hardening	回火 Tempering
  1	1.50	0.35	0.35	0.030	0.030	12.10	≤0.40	0.85	0.60		255	1010-1050	200 530	62-63
  2	1.50	0.35	0.50	0.030	0.030	12.00	—	0.75	0.35		255	1020-1040	160	62-63
  3	1.60	0.35	0.35	0.030	0.030	12.00	—	0.50	0.20		255	1020-1040	250	57-59
  4	2.10	0.35	0.35	0.030	0.030	12.40	—	—	—		255	950-980	200	62
  5	1.00	1.00	0.45	0.030	0.030	8.20	0.80	1.80	0.70		255	1010-1050	520	61-63
  6	2.20	0.90	0.40	0.030	0.030	12.50	≤0.90	—	—		255	1010-1100	530	54-61
  7	0.52	0.90	0.35	0.030	0.030	8.20	≤1.75	1.50	0.40		255	1010-1050	500	56
  8	1.00	0.40	0.75	0.030	0.030	5.10	—	1.10	0.30		255	940-960	200	60-63
  9	0.93	0.30	1.20	0.030	0.030	0.50	0.50	≤0.30	0.23		217	800-820	200	60-62
  10	1.95	0.35	0.50	0.030	0.030	1.90	—	0.25	0.18		255	830	200	62
